NBL-ZS-106 Online Turbidity Water Sensor

NBL-ZS-106 integrated online turbidity sensor is designed and manufactured using the principle of scattered light turbidity measurement. When a beam of light is incident on a water sample, the light is scattered by the turbidity substance in the water sample, and the intensity of the scattered light in the direction perpendicular to the incident light is measured and compared with the internal calibration value to calculate the turbidity in the water sample. Degree, linearized to output the final value. 90° angle scattered light principle, built-in temperature sensor Support RS-485, Modbus/RTU protocol Optical fiber structure, strong resistance to external light interference Infrared LED light source with high stability IP68 protection, water depth within 20 meters Convenient, fast, stable and easy to maintain
