PM2.5, PM10 sensor supplier

The integrated PM2.5, PM10 sensor adopts the laser scattering principle, combining imported lasers and light-sensing components with high accuracy, reliability and stability, and is capable of sensitively detecting PM2.5 and PM10 concentrations in the air. The built-in fan design enhances the efficiency of airflow sampling and is highly integrated for a variety of application scenarios. The sensor can adjust the power supply voltage according to the actual demand, and provide a variety of signal output forms, flexible to meet the system requirements of different users.

 Integrated PM2.5, PM10 Sensor Technical Parameters

- Measuring range:

  - PM2.5: 0-1000 μg/m³

  - PM10: 0-2000 μg/m³

- Relative Error:

  - PM2.5, PM10: ±15% and ±10 μg/m³ of the maximum error (at 25 ℃, 50% RH ambient conditions)

- Minimum detection particle: 0.3 μm diameter

- Power supply: DC 12V-24V

- Output: RS485

- Instrument cable length: standard: 2.5 meters (other lengths are optional)

- Ambient Temperature: -20℃ ~ +60

- Ambient humidity: 0 ~ 99% RH

Integrated PM2.5, PM10 sensor key features

1. High precision and reliability: Through laser scattering technology and imported components, the sensor can detect tiny PM2.5 and PM10 particles in the air with high precision, ensuring stable and reliable data.

2. High integration: The built-in fan design enables the sensor to sample efficiently and ensure stable operation in different working environments.

3. Flexible Voltage and Signal Outputs: Supports a variety of voltage and signal output options to adapt to different equipment and system requirements.

4. Wide operating temperature and humidity range: adapt to the temperature and humidity changes in different environments to ensure the long-term stability of the equipment.

 PM2.5, PM10 integrated sensor application areas

- Air quality monitoring: suitable for real-time monitoring of PM2.5, PM10 concentration in indoor and outdoor environments to help realize air quality management.

- Environmental monitoring systems: integrated into environmental monitoring stations, air purification systems, air quality alarm systems.

- Industrial applications: Used for monitoring harmful dust in industrial production to protect employee health and production environment safety.

- Intelligent building system: integrated with intelligent building management system to monitor air quality in buildings in real time and optimize air conditioning and ventilation systems.

NBL-W-PM2.5&PM10 sensor not only provides accurate PM2.5 and PM10 concentration data, but also can adapt to a variety of environmental conditions, is an indispensable and important part of the air quality monitoring system.
