Piezoelectric Rain Gauge Suppliers

Introduction to Piezoelectric Rain Gauge

Niubol is dedicated to the research and development of advanced meteorological monitoring equipment, particularly high-performance piezoelectric rain gauges. This product utilizes piezoelectric ceramic kinetic energy rain measurement technology, which can accurately and rapidly detect precipitation from light rain to heavy downpours, offering extremely high measurement precision.

Principle of Piezoelectric Rain Gauge Technology

The piezoelectric rain gauge detects the kinetic energy generated by raindrops striking the sensor surface. By considering factors such as the weight of the raindrops and air resistance, it accurately calculates the impact force of each raindrop, thereby estimating the rainfall. During the fall of the raindrops, according to the formula P = mv (momentum = mass × velocity), the device measures the impact force of the raindrop to determine its weight and ultimately calculates the continuous rainfall, ensuring accurate data even during heavy rainfall.

Features of the Piezoelectric Rain Gauge

- Efficient Processor: Equipped with an industrial-grade 32-bit processor, ensuring faster calculation speeds and more stable performance.

- Self-Cleaning Design: The arc-shaped structure and anti-fouling coating allow the rain gauge to automatically clean itself, eliminating the need for manual maintenance and greatly reducing daily upkeep.

- Integrated Structure: The product features an integrated design, making it compact with no exposed parts, ensuring durability and sturdiness.

- High Precision Measurement: Capable of accurately measuring rainfall intensity from light to heavy rain, providing reliable and precise data.

- Strong Portability: Small, lightweight, and easy to transport, suitable for a variety of application scenarios.

- Easy Installation: No special installation environment is required, and it does not need physical leveling calibration or field calibration. It can start measuring immediately after installation.

Applications of the Piezoelectric Rain Gauge

The piezoelectric rain gauge is widely used in rainfall measurement, agricultural irrigation, environmental meteorological monitoring, meteorological disaster monitoring, and automatic rain sensing systems. Its high precision, reliability, and low maintenance cost make it an essential tool for modern meteorological monitoring.

Our Advantages

As the manufacturer of this product, we not only provide high-quality equipment but also possess a strong R&D team and comprehensive after-sales support. Whether it's optimizing product performance or providing technical support later on, we strive to offer our customers all-around service to ensure the best user experience.

Piezoelectric Rain Gauge data sheet

NBL-W-PRS-Piezoelectric-Rain-Sensor-Operator's-Manual.pdf
