1. Application Background

Coal is a critical energy source in China, and its mining safety directly impacts the lives of workers and the sustainable development of enterprises. The underground environment is complex, with high dust concentration and restricted air circulation. Excessive dust can lead to pneumoconiosis, and the accumulation of harmful gases like methane and carbon monoxide can trigger explosion accidents.

Traditional manual inspections face issues such as data lag, incomplete coverage, and human errors, making it difficult to meet the modern coal mine's requirements for precise and real-time monitoring. To address this, NiuBoL has launched a high-precision, real-time, full-link control coal mine environment monitoring solution, focusing on dust and underground air quality, offering comprehensive safety assurance for coal mine enterprises.

 2. Core Issues

- Dust Control Challenges: Traditional fixed-point sampling is delayed, with many monitoring blind spots.

- Air Quality Monitoring Delays: The dynamic changes in gas concentrations, combined with traditional equipment's limited functionality and manual reporting, increase the risk of data omission.

- Low Data Utilization Efficiency: Monitoring data is scattered, lacking a unified analysis platform, making it difficult to form safety decisions.

- Delayed Emergency Response: Over-limit events require manual confirmation and sequential reporting, which can miss the optimal processing window.

 3. Solution Overview

Core Goals: Real-time monitoring, accurate early warning, intelligent decision-making, and efficient control. By using high-precision sensors and smart collection devices, this solution continuously monitors dust, harmful gases (methane, carbon monoxide, hydrogen sulfide, etc.), temperature, humidity, and other parameters 24/7. It transforms data into visual information and early warning signals, helping enterprises respond quickly to environmental anomalies, reduce accident risks, and comply with regulations.

Core Technologies:

- High-Precision Sensing Technology: Laser scattering principle for dust sensors with precision up to 0.01mg/m³, simultaneous monitoring of PM2.5 and PM10; electrochemical/infrared gas sensors with an error margin of less than ±2%.

- Industrial-Grade Data Transmission: Mine Ethernet + LoRa dual backup, with transmission latency <500ms, ensuring high reliability.

- Mobile Connectivity and Visualization: WebGIS + App for real-time data and early warning information, supporting remote management.

 4. Key Components

Front-End Sensing Layer:

- NiuBoL Dust Sensors: PM2.5, PM10 dual parameter monitoring, with a resolution of 0.01mg/m³, supports 485/LoRa output.

- Multi-parameter Air Sensors: Monitors methane, carbon monoxide, hydrogen sulfide, oxygen, etc., using infrared/electrochemical principles, with onsite sound and light alarms.

- Auxiliary Equipment: Temperature and humidity sensors, wind speed sensors, to support environmental parameter monitoring.

Data Transmission Layer:

- Mine Data Collectors: Supports multiple protocols, edge computing capabilities, explosion-proof design, and supports Ethernet, LoRa, 4G/5G transmission.

- Network Optimization: Flame-retardant Ethernet + LoRa wireless coverage underground, with 4G/5G connection to the cloud, achieving 99.9% transmission reliability.

Platform Layer:

- NiuBoL Intelligent Cloud Platform: Data storage for ≥1 year, intelligent analysis, trend prediction, anomaly warning, WebGIS visualization monitoring, and multi-level warning management.

Application Layer:

- Client App: Real-time data viewing, anomaly alerts, mobile inspections, and remote device status management.

- Web Management Console: System configuration, permissions management, report generation, and maintenance management.

 5. Implementation Steps

Device Installation:

- Point Layout: Deploy sensors every 50 meters in high-dust areas, gas sensors at tunnel intersections.

- Installation and Debugging: Fixed installation of sensors, wiring standards, and network connection testing.

- System Commissioning: Integrate the devices with the cloud platform and App to ensure data synchronization and early warning functionality.

Data Collection and Analysis:

- Data Collection: Sensors collect data every second, while collectors upload valid data every 5 seconds.

- Data Preprocessing: The cloud platform cleanses abnormal data to ensure accuracy.

- Intelligent Analysis: Trend prediction and generation of "Coal Mine Environment Monitoring Analysis Report" to guide ventilation and mining adjustments.

Decision Support:

- Multi-level Early Warnings: First-level alert, second-level notification, third-level triggering of sound and light alarms with ventilation system linkage.

- Data-Driven Decision-Making: Optimizes mining plans and ventilation parameters, reducing dust and gas exceedance risks.

- Compliance Management: Automatically records monitoring and alert processing, generating regulatory-compliant reports.

 6. Core Advantages

- High-Precision Monitoring: Dust error ≤ ±5%, gas ≤ ±2%, reliable data.

- Full-Link Control: Data delay <1 second, early warning push ≤3 seconds.

- Intelligent Analysis: Predicts risk trends, shifting from post-incident remediation to preemptive prevention.

- High Adaptability: Explosion-proof, dust-proof, moisture-proof, MTBF > 20,000 hours.

- Brand Assurance: 10 years of R&D experience, full-process professional services.

 7. Challenges and Responses

- Technical Costs: Prioritize core areas for high-end sensors, and use cost-effective sensors for secondary areas.

- Adaptability Issues: Custom solutions and quarterly inspections ensure equipment stability.

- Operational Risks for Personnel: Training on App usage, simplified interfaces, one-click operations.

 FAQ

Q1: What parameters are monitored?

A1: Dust (PM2.5/PM10), methane, carbon monoxide, hydrogen sulfide, oxygen, with expandable options for temperature, humidity, and wind speed.

Q2: What types of coal mines are suitable?

A2: Suitable for underground coal mines, including excavation areas, recovery areas, transport tunnels, and electromechanical chambers, with customizable deployment.

Q3: How are abnormal data handled?

A3: Multi-level warnings, on-site sound and light alarms, cloud platform dispatching suggestions, and closed-loop management.

Q4: What is the precision of the dust sensor?

A4: Precision of 0.01mg/m³, error ≤ ±5%, in compliance with regulations.

Q5: How stable is the underground network?

A5: Wired + LoRa dual backup, with 99.9% transmission reliability and complete coverage.

Q6: How is data stored and secured?

A6: Default storage for 1 year, extendable to 3 years, encrypted storage with multi-level backups, in compliance with regulations.

Q7: What is the implementation cycle?

A7: Small coal mines take about 15 days, large coal mines about 30 days, including site survey, installation, debugging, and training.

Q8: What are the maintenance costs?

A8: Equipment MTBF > 20,000 hours, with free/annual maintenance services and remote support.

Q9: What if frontline staff cannot operate the system?

A9: Training, manuals, and video tutorials are provided, with a user-friendly interface for easy operation.

 Summary

Coal mine environmental safety is vital for both worker lives and the enterprise's development. The NiuBoL Coal Mine Environment Monitoring Solution, using high-precision sensors, stable data transmission, intelligent cloud platforms, and mobile applications, achieves real-time monitoring, intelligent analysis, accurate early warning, and scientific decision-making for full-link control.

Core Advantages: High precision, fast response, intelligent foresight, high adaptability, and full-service support, reducing environmental safety risks, helping enterprises comply with regulations, and improving safety management levels.
