Weather Stations

8-in-1 Ultrasonic Weather Station Sensor with PM2.5 PM10 Noise | NBL-W-81GUWS

8-in-1 Ultrasonic Weather Station Sensor with PM2.5 PM10 Noise | NBL-W-81GUWS

NBL-W-81GUWS 8-in-1 Integrated Ultrasonic Weather Station adopts fully digital detection technology and high-precision sensors, which can quickly and accurately measure eight key environmental parameters such as wind speed, wind direction, atmospheric temperature, humidity, pressure, PM2.5, PM10 and noise. Whether in the field of meteorological monitoring, environmental protection, airport management, port operation, laboratory research, industrial and agricultural production···

Inquiry

Tel/WhatsApp:+8615367865107

Email:Arvin@niubol.com +Nearly 100 partner companies in more than 75 countries. We are committed to providing high-quality, practical products to meet your needs and help you solve problems. Our products comply with international standards and are certified with ISO, CE and RoHS.

Product Details

NBL-W-81GUWS 8-in-1 Ultrasonic Weather Station Sensor

The NBL-W-81GUWS 8-in-1 ultrasonic weather station sensor combines wind speed, wind direction, air temperature, relative humidity, barometric pressure, PM2.5, PM10 and environmental noise measurement in one integrated outdoor sensor.

The ultrasonic wind measurement system provides a wind speed range of 0–60 m/s without conventional rotating wind cups or a mechanical wind vane. Integrated particulate matter sensing measures PM2.5 and PM10, while the noise channel provides sound level data from 30 to 130 dB.

With RS485 Modbus RTU communication, this multi-parameter weather and environmental sensor can connect to compatible data loggers, PLCs and IoT gateways for meteorological monitoring, air-quality monitoring, airports, ports, transportation, industrial sites and environmental monitoring networks.

NBL-W-81GUWS 8-in-1 ultrasonic weather station sensor installed outdoors

8-in-1 Ultrasonic Weather Station Sensor Specifications

ParameterMeasurement RangeAccuracyResolution
Wind Speed0–60 m/s±0.3 m/s + 3% F.S.0.01 m/s
Wind Direction0–359°±3°1°
Air Temperature-40 to 80°C±0.5°C0.1°C
Relative Humidity0–100% RH±5% RH0.1% RH
Barometric Pressure10–1100 hPa±1.5 hPa0.1 hPa
PM2.50–1000 µg/m³±10%1 µg/m³
PM100–2000 µg/m³±10%1 µg/m³
Noise30–130 dB±5 dB0.1 dB
ModelNBL-W-81GUWS
Product Type8-in-1 Ultrasonic Weather & Environmental Sensor
Measured ParametersWind Speed, Wind Direction, Temperature, Humidity, Barometric Pressure, PM2.5, PM10, Noise
Wind Measurement PrincipleUltrasonic Transit-Time Measurement
Power SupplyDC 9–24V
Signal OutputRS485
ProtocolModbus RTU
Baud Rate9600 bps
Average Power ConsumptionApprox. 1 W with particulate matter sensor
Operating Temperature-40 to 80°C
Operating Humidity0–95% RH
Protection RatingIP65

Eight Weather and Environmental Parameters in One Sensor

This 8-in-1 ultrasonic weather station sensor combines five core meteorological parameters with PM2.5, PM10 and environmental noise measurement, allowing weather and basic air-quality conditions to be monitored from one integrated device.

ParameterWhat It MeasuresTypical Application
Wind SpeedWind velocity up to 60 m/sMeteorology, airports, ports and transportation
Wind DirectionDirection from which the wind is blowingMeteorology and pollutant dispersion monitoring
Air TemperatureAmbient atmospheric temperatureWeather, agriculture and environmental monitoring
Relative HumidityAtmospheric moistureEnvironmental and meteorological monitoring
Barometric PressureAtmospheric pressureWeather and aviation monitoring
PM2.5Fine airborne particulate matterAir-quality and environmental monitoring
PM10Coarse inhalable particulate matterDust and ambient air-quality monitoring
NoiseEnvironmental sound level in dBIndustrial, traffic and environmental monitoring

NBL-W-81GUWS ultrasonic weather station sensor detail

Ultrasonic Wind Speed and Direction Measurement

The ultrasonic wind measurement system compares the transit time of sound signals between opposing north-south and east-west transducers. Airflow changes the signal travel time in different directions, allowing wind speed and wind direction to be calculated without conventional rotating wind cups or a mechanical wind vane.

The integrated ultrasonic wind sensor measures wind speeds from 0 to 60 m/s with 0.01 m/s resolution, supporting meteorological, transportation, port and environmental monitoring applications.

PM2.5 and PM10 Air-Quality Monitoring

The ultrasonic weather sensor with PM2.5 and PM10 combines meteorological measurements with particulate matter monitoring. PM2.5 represents fine airborne particles, while PM10 covers larger inhalable particulate matter.

ParameterRangeResolutionTypical Use
PM2.50–1000 µg/m³1 µg/m³Fine particulate air-quality monitoring
PM100–2000 µg/m³1 µg/m³Dust and inhalable particulate monitoring

For projects that require regulatory-grade particulate monitoring, reference-method equivalence, specific certification or traceable calibration, provide those requirements before model selection.

Environmental Noise Measurement

The integrated noise channel measures environmental sound levels from 30 to 130 dB with 0.1 dB resolution. It can be used together with weather and particulate data for distributed environmental monitoring systems.

For projects requiring specific acoustic indicators such as LAeq, Lmax, Lmin, frequency weighting, time weighting or regulatory noise compliance, provide the required specification before model selection.

Key Features

FeatureValue
8-in-1 MeasurementFive meteorological parameters plus PM2.5, PM10 and noise
0–60 m/s Wind RangeSuitable for meteorological and transportation monitoring
Ultrasonic Wind MeasurementNo conventional rotating wind cups or mechanical wind vane
PM2.5 + PM10Adds particulate matter monitoring to basic meteorological measurements
Noise Measurement30–130 dB environmental sound level measurement
RS485 Modbus RTUDigital connection to compatible PLCs, data loggers and IoT gateways
IP65 ProtectionDesigned for outdoor environmental monitoring

NBL-W-81GUWS ultrasonic weather and environmental monitoring sensors

Ultrasonic Weather Sensor RS485 Modbus Integration

The ultrasonic weather sensor with RS485 Modbus can connect to compatible environmental data loggers, PLCs and IoT gateways. Meteorological, particulate matter and noise measurements can be acquired through the same digital communication interface.

Communication ItemSpecification
InterfaceRS485
ProtocolModbus RTU
Baud Rate9600 bps
Data Bits8
ParityNone
Minimum Communication Interval1000 ms
Read Function Code03
Device Address Range0–255

Modbus Data for the 8-in-1 Configuration

MeasurementResolution
Wind Speed0.01 m/s
Wind Direction1°
Air Temperature0.1°C
Relative Humidity0.1% RH
Barometric Pressure0.1 hPa
PM2.51 µg/m³
PM101 µg/m³
Noise0.1 dB

Wiring

Wire ColorFunction
RedPower Positive
BlackPower Negative
YellowRS485 A+
BlueRS485 B-

Use the markings on the supplied communication cable as the final wiring reference. Complete and verify all wiring before applying power.

Ultrasonic Weather Station Sensor Dimensions

NBL-W-81GUWS 8-in-1 ultrasonic weather station sensor dimensions

Installation Recommendations

Install the ultrasonic weather station sensor vertically in an open location with representative airflow and ambient air exposure. Correct north alignment is required for wind direction measurement, while the particulate and noise sensing sections should remain unobstructed by surrounding structures.

Installation ItemRecommendation
MountingInstall the sensor securely on a stable vertical mounting pipe.
North AlignmentAlign the sensor's north reference point with geographic north before final fixing.
Wind ExposureAvoid nearby buildings, trees, poles and structures that may disturb airflow.
PM MonitoringInstall where ambient air can reach the particulate matter sensing section without obstruction.
Noise MonitoringChoose a representative location and avoid unintended local mechanical noise sources unless they are the intended monitoring target.
Radar / Radio EquipmentMaintain at least 2 m separation from radar scanning equipment and avoid strong radio interference.
VibrationAvoid strong mechanical vibration sources.
CableProvide suitable strain relief and protect outdoor wiring from mechanical damage.

Weather and Environmental Monitoring System Integration

8-in-1 Ultrasonic Weather Station Sensor → RS485 Modbus RTU → Data Logger / PLC / IoT Gateway → Cloud Platform or Private Server

The sensor provides weather, particulate matter and noise measurements through RS485 Modbus RTU. Remote transmission through 4G, Ethernet, Wi-Fi or LoRaWAN requires a compatible data logger or IoT gateway; these communication functions are not built into the sensor itself.

Meteorological, Air Quality and Environmental Monitoring Applications

Thisenvironmental monitoring weather sensoris suitable where meteorological conditions, particulate matter and environmental noise need to be monitored from one location. Typical projects include automatic weather stations, urban environment monitoring, transportation, airports, ports and industrial sites.

Automatic Weather Stations  •  Air Quality Monitoring  •  Environmental Monitoring  •  Airports & Aviation
Ports & Harbors  •  Transportation Monitoring  •  Industrial Sites  •  Urban Monitoring

8-in-1 ultrasonic weather station sensor applications for environmental transportation ports and automatic weather stations

8-in-1 Weather Sensor vs Standard Meteorological Sensor

ParameterBasic 5-in-1 Weather SensorNBL-W-81GUWS 8-in-1
Wind Speed & DirectionYesYes
Temperature / Humidity / PressureYesYes
PM2.5NoYes
PM10NoYes
NoiseNoYes
Typical SelectionBasic meteorological monitoringCombined meteorological, particulate matter and noise monitoring

How to Select the Right Integrated Weather Sensor

Project RequirementRecommended Selection
Wind + Temperature + Humidity + Pressure only5-in-1 ultrasonic weather sensor
Meteorological Parameters + PM2.5 + PM10 + NoiseNBL-W-81GUWS 8-in-1 ultrasonic weather station sensor
Rainfall RequiredSelect a configuration that specifically includes rainfall measurement
Solar Radiation or Illuminance RequiredSelect the appropriate higher-parameter configuration or dedicated radiation/light sensor
Regulatory PM or Noise Compliance RequiredConfirm the required reference method, acoustic indicators, calibration and certification before model selection
Complete Remote Environmental StationAdd a compatible data logger, communication gateway, power supply and mounting system

FAQ

Q1. What does the NBL-W-81GUWS 8-in-1 ultrasonic weather station sensor measure?

A1. It measures wind speed, wind direction, air temperature, relative humidity, barometric pressure, PM2.5, PM10 and environmental noise.

Q2. What is the wind speed measurement range?

A2. The ultrasonic wind speed range is 0–60 m/s with 0.01 m/s resolution.

Q3. What particulate matter parameters does the sensor measure?

A3. The 8-in-1 configuration measures PM2.5 from 0–1000 µg/m³ and PM10 from 0–2000 µg/m³.

Q4. What is the noise measurement range?

A4. The integrated noise channel has a measurement range of 30–130 dB with 0.1 dB resolution.

Q5. Does the ultrasonic weather sensor support RS485 Modbus RTU?

A5. Yes. It provides RS485 Modbus RTU communication at 9600 bps for compatible data loggers, PLCs and IoT gateways.

Q6. Does the NBL-W-81GUWS measure rainfall?

A6. The standard 8-in-1 configuration on this page measures wind speed, wind direction, temperature, humidity, pressure, PM2.5, PM10 and noise. Select a configuration that specifically includes rainfall if rainfall measurement is required.

Q7. Is the PM measurement intended for regulatory air-quality monitoring?

A7. The sensor provides particulate matter data for environmental monitoring. For projects requiring regulatory-grade measurements, reference-method equivalence, certified calibration or specific local compliance, provide those requirements before model selection.

Q8. Does the noise channel provide LAeq or other regulatory acoustic indicators?

A8. For projects requiring LAeq, Lmax, Lmin, frequency weighting or other specific acoustic indicators, provide the required specification before model selection.

Q9. Does the sensor include built-in 4G, Wi-Fi or LoRaWAN?

A9. No. The sensor provides RS485 measurement data. Remote transmission requires a compatible data logger or IoT gateway with the required 4G, Wi-Fi, Ethernet or LoRaWAN communication function.

Q10. Is the 8-in-1 sensor suitable for environmental monitoring stations?

A10. Yes. It combines meteorological parameters with PM2.5, PM10 and noise measurement, making it suitable for distributed weather and environmental monitoring systems where these eight parameters are required.

NBL-W-81GUWS Ultrasonic Weather Station Sensor Instruction Manual

PDFNBL-W-81GUWS-8-in-1-Ultrasonic-Weather-Station-Sensor-Instruction-Manual.pdf

Quotation and Model Selection

For quotation and model selection, specify the required eight parameters, quantity, power supply, cable length, installation environment and the PLC, data logger or IoT gateway that will receive the RS485 Modbus data. If rainfall, solar radiation, illuminance, regulatory particulate monitoring, specific acoustic indicators or other environmental measurements are required, include them with the inquiry so the appropriate integrated weather sensor configuration can be selected.
