NBL-S-PH Soil pH Sensor for Export to Thailand

NiuBoL NBL-S-PH Soil pH Sensor for Export to Thailand

The NiuBoL NBL-S-PH is a high-precision, low-power soil pH measurement sensor designed to address the pain points of traditional pH testing systems, such as large size, high cost, complex calibration, and integration difficulties.

With a compact structure and easy installation, it is suitable for various applications, including smart agriculture, irrigation control systems, horticulture, grassland and pasture management, and scientific research experiments.

Overview of Thailand

Located in the central-southern peninsula of Southeast Asia, agriculture is a key pillar of Thailand’s economy. Approximately 40% of the population is engaged in agricultural production, primarily growing crops such as rice, sugarcane, rubber, corn, and cassava. Thailand’s tropical monsoon climate provides abundant rainfall and high temperatures, but soil pH varies significantly across regions, with acidic soils prevalent in the northern mountains and southern coastal areas. Accurate soil pH monitoring is critical for improving crop yields and fertilizer efficiency.

The introduction of the NiuBoL soil pH sensor offers an efficient solution for modernizing Thai agriculture and enabling precision fertilization.

Applications of the NiuBoL Soil pH Sensor

- Agricultural irrigation and smart agriculture systems

- Floriculture and horticulture

- Grassland and pasture management

- Soil fertility monitoring and rapid analysis

- Scientific research and educational experiments

- Plant cultivation and greenhouse control

Technical Specifications of the NiuBoL Soil pH Sensor

Measurement Range：0–14 pH

Accuracy：±0.1 pH

Resolution：0.01 pH

Response Time：<10 seconds (in water)

Power Supply：DC 12V–24V

Output Signal：0–5V / 4–20mA / RS485 (Modbus)

Cable Length：Standard 5 meters

Power Consumption：0.2W

Operating Environment：Temperature: 0–80°C, Humidity: 0–95% RH

Housing Material：Waterproof plastic housing

Usage Instructions (Key Points)

- Remove the probe’s protective cap before use and install the filter slot and filter net to prevent direct soil contact with the electrode.

- Insert the probe into the soil, ensuring the depth exceeds the filter net position.

- During measurement, pour a small amount of water around the probe and wait for the moisture to penetrate before reading stable values.

- Use the provided three pH reagents to verify sensor performance.

Advantages of the NiuBoL Soil pH Sensor

- High Precision & Fast Response: Response time <10 seconds, providing real-time soil pH status.

- Low Power & Easy Integration: Only 0.2W power consumption, compatible with multiple signal output formats.

- Waterproof & Durable Design: Waterproof plastic housing, suitable for high-humidity and high-temperature environments.

- Low Maintenance: No frequent calibration required, with simple and reliable installation and use.

Summary

The NiuBoL NBL-S-PH soil pH sensor, with its high precision, low power consumption, strong compatibility, and compact design, is ideally suited for export to Thailand’s smart agriculture and environmental monitoring projects.

In Thailand’s tropical climate and diverse soil conditions, this sensor enables farmers and research institutions to monitor soil pH changes in real time, providing scientific guidance for fertilization and crop management. It supports Thailand’s agriculture in advancing toward digitalization and precision farming.
