Weather Station Sensors & Integrated Ultrasonic Weather Sensors

NiuBoL provides weather station sensors and integrated ultrasonic weather sensors for measuring wind speed, wind direction, air temperature, relative humidity, atmospheric pressure, rainfall, solar radiation and other meteorological parameters.

This category includes individual meteorological sensors and compact multi-parameter weather sensors such as 5-in-1, 6-in-1, 7-in-1 and other integrated configurations. These products can be connected to a compatible data logger or controller to build an automatic weather monitoring system.

If you are selecting a complete station with mast, data logger, power system and remote communication, see the Automatic Weather Station selection page.

Integrated vs Modular Weather Station Sensors

Weather monitoring systems can use either a compact integrated sensor or separate individual instruments. The correct structure depends on installation space, required parameters, maintenance strategy and measurement-performance requirements.

Choosing a 5-in-1, 6-in-1, 7-in-1 or Multi-Parameter Weather Sensor

The number in an integrated weather sensor name refers to the number of measurement parameters included in that specific configuration. The exact parameter combination should always be checked on the individual product page rather than assumed from the number alone.

Common integrated parameters can include wind speed, wind direction, air temperature, relative humidity, atmospheric pressure, rainfall or solar radiation depending on the selected model. Some projects require additional standalone instruments when higher-performance solar radiation, precipitation or other measurements are needed.

Ultrasonic vs Mechanical Wind Measurement

Ultrasonic wind sensors measure wind speed and direction without rotating cups or vanes, reducing moving-part maintenance. Mechanical wind sensors use cup anemometers and wind vanes and remain widely used in conventional meteorological stations. Selection should consider required accuracy, starting threshold, icing or contamination risk, maintenance access and project budget.

Weather Sensor Output and System Integration

Many NiuBoL weather sensors use RS485 Modbus for connection to a compatible data logger, PLC, RTU or IoT gateway. Other signal types can be available depending on the product.

Weather Sensors → RS485 / Other Signal → Data Logger / PLC / RTU → 4G / Ethernet / Wi-Fi / LoRaWAN → Cloud / SCADA / Private Server

Remote communication is normally provided by the data logger or gateway. A basic weather sensor should not automatically be assumed to include cellular or cloud communication unless the specific model states otherwise.

Typical Applications

Agricultural Monitoring   •   Environmental Monitoring   •   Hydrology   •   Solar Energy
Research Stations   •   Road Weather   •   Industrial Sites   •   Remote IoT Stations

How to Select Weather Station Sensors

Weather Station Sensor FAQ

Q1. Is an integrated weather sensor a complete automatic weather station?

A1. Not necessarily. An integrated sensor measures several meteorological parameters, while a complete automatic weather station may also include a data logger, mast, power system, enclosure and remote communication equipment.

Q2. What is the advantage of an ultrasonic weather sensor?

A2. Ultrasonic wind measurement has no rotating cups or vanes, which reduces moving-part maintenance and supports compact integrated designs.

Q3. Can I connect the sensors to my own data logger?

A3. Yes, when the electrical interface and communication protocol are compatible. Confirm the sensor output, power supply and Modbus register information before integration.

Q4. Can weather data be sent to my own server?

A4. Yes, by using a compatible data logger or IoT gateway that supports the required remote communication and server protocol.

Q5. What information is required for a quotation?

A5. Provide the required parameters, ranges and accuracy, integrated or separate-sensor preference, output interface, installation method, data logger or platform requirement and quantity.

Need a Complete Automatic Weather Station?

If your project requires sensors together with a mast, data logger, solar power, battery, 4G communication, cloud platform or private-server integration, see the Automatic Weather Station selection guide or send the complete project requirements for system configuration.
