Company news
Time:2025-10-23 11:01:35 Popularity:1195
NiuBoL exported NBL-S-TMC soil sensors to New Zealand. The three measurement channels combine soil temperature, moisture and electrical conductivity in a probe intended for agricultural and environmental monitoring.

Soil temperature provides context for root-zone conditions. Moisture data can help the operator follow drying and wetting cycles, while conductivity adds information about changes associated with dissolved salts. These values are most useful when their location, depth and recent irrigation conditions are known.
The moisture channel uses a dielectric measurement method. Soil texture, density, salinity and contact around the electrodes can influence comparison between points. Conductivity is a separate channel and should not automatically be interpreted as the concentration of an individual nutrient.
Comparable configurations may be used in horticulture, orchards, pasture studies or irrigation monitoring. The appropriate number of probes depends on management zones and soil variability. A point close to an emitter can behave differently from one between crop rows.

The selected output must match the data logger or controller. For an RS485 Modbus RTU version, confirm power, addressing, register definitions and engineering units before installation. A logger or gateway provides any required onward network connection.
Buried installations need protected cable routes and sound soil contact. Record the installed depth and point identity so later maintenance or replacement does not change the meaning of the data.

NiuBoL supplies soil instruments for individual measurement points and integrated monitoring projects. Send the required parameters, output, cable length, quantity and existing acquisition equipment to review a comparable configuration. The NBL-S-TMC product page provides the model reference.
