What is PM10 Monitoring Equipment?

PM10 refers to inhalable particulate matter with a diameter of 10 micrometers or less, which can penetrate the respiratory system and even reach the lungs, significantly affecting human health. It is especially important to monitor in areas with dense urban traffic or industrial emissions.

PM10 monitoring equipment is a specialized instrument used to measure the concentration of airborne particles with a diameter of 10 micrometers or less (PM10) in real-time. These particles include dust, smoke, pollen, and mold, which can enter the respiratory system and cause significant impacts on health and the environment. PM10 monitoring equipment usually employs technologies such as laser scattering, beta-ray absorption, or gravimetric methods to accurately detect the concentration of particles in the air. The data is then converted into a standard electrical signal, integrated into a data collection platform or air quality monitoring system to provide real-time, continuous, and reliable pollution level data.

The Role and Value of PM10 Monitoring Equipment:

- Health Protection: PM10 particles can enter the upper respiratory tract, leading to respiratory diseases such as asthma and bronchitis. Monitoring equipment provides real-time data to help identify high pollution areas, alert the public to take protective measures, such as wearing masks or reducing outdoor activities.

- Environmental Management: Provides accurate data for environmental agencies to support the formulation and evaluation of air quality policies, reducing pollution’s impact on the ecosystem and visibility.

- Real-time Warnings: When PM10 concentrations exceed safety thresholds, the equipment can trigger alarms, notifying relevant departments and the public to take emergency measures, reducing health risks.

- Data Support: Provides high-resolution spatial and temporal data for scientific research, urban planning, and industrial emission control, helping analyze pollution sources and diffusion patterns.

- Compliance Monitoring: In industrial and construction environments, ensures that PM10 concentrations comply with regulatory requirements, protecting the health of workers and surrounding communities.

Applications of PM10 Monitoring Equipment:

PM10 monitoring equipment is widely used in the following scenarios:

- Urban Air Quality Monitoring: Deployed in city monitoring stations to track PM10 concentration in real-time, supporting smart city air quality management.

- Industry and Construction Sites: Monitors dust emissions from factories, mines, and construction sites to ensure compliance with occupational health and environmental standards.

- Public Places: Monitors air quality in schools, parks, hospitals, and other public areas, protecting the health of sensitive groups such as children and the elderly.

- Environmental and Scientific Research: Provides data for atmospheric science and pollution research, analyzing the sources and effects of PM10.

- Traffic Areas: Monitors PM10 generated by road traffic, such as brake and tire wear emissions, optimizing traffic management.

Recommended Product: NBL-W-PM Integrated PM2.5 / PM10 Sensor

The NBL-W-PM sensor is a high-performance, integrated PM2.5 and PM10 monitoring device that uses the laser scattering principle. It is equipped with imported lasers and light-sensitive components to ensure stable and reliable data. The sensor comes with an internal fan and highly integrated design, supporting flexible power supply voltages (DC 12V-24V) and multiple output forms (such as RS485), making it easy to integrate into different systems. It is suitable for a wide temperature range of -20°C to 60°C and a humidity range of 0-99% RH, with a low power consumption of only 350mW, making it ideal for long-term outdoor monitoring.

Technical Parameters of the NBL-W-PM PM2.5 and PM10 Integrated Monitoring Device:

Advantages of the Integrated PM2.5 / PM10 Sensor:

- High Accuracy and Stability: Uses imported lasers for reliable data, suitable for high-precision monitoring needs.

- Flexible Integration: Supports various output forms, making it easy to connect with environmental monitoring systems.

- Durable Design: Adapted for harsh outdoor environments, with high protection level and low maintenance cost.

- Low Power Consumption: With only 350mW of power consumption, it is suitable for continuous long-term operation.

- Dual Parameter Detection: Outputs both PM2.5 and PM10 concentrations simultaneously.

- Multiple Output Methods: Supports RS485, customizable TTL, voltage, and current outputs.

- Flexible Power Supply: 12V-24V wide voltage input, strong compatibility.

Reasons for Recommendation:

The NBL-W-PM sensor, with its high cost-performance ratio and reliable performance, is particularly suitable for urban air quality monitoring stations, industrial dust monitoring, and environmental research projects. Its compact design and low maintenance requirements make it easy to deploy in various outdoor scenarios, providing users with accurate PM10 and PM2.5 data, aiding health protection and environmental management.

Contact Us:

For more information on the NBL-W-PM sensor or to get an air quality monitoring solution, please visit our website or contact our team. We will provide you with customized support and services.

PM2.5, PM10, Integrated Sensor Data Sheet

NBL-W-PM25-PM10-Integrated-sensors-Manual.pdf
