Soil sensors are instruments used to measure physical, chemical and water-related properties of soil. They provide information about conditions such as soil temperature, moisture, electrical conductivity (EC), pH, soil water potential and heat transfer. Specialized instruments can also measure soil gases or provide estimated nutrient indicators.
Different soil measurements require different sensing principles. A soil moisture probe, for example, measures water content using the electrical properties of soil, while a tensiometer measures the energy state of soil water through pressure. A soil pH electrode measures electrochemical potential, and a soil heat flux plate measures heat transfer.
The following guide explains 10 types of soil sensors, their working principles, measurement units, agricultural applications and important limitations. It also distinguishes individual sensor technologies from multi-depth and portable instrument configurations.
| No. | Sensor Type | Measurement | Typical Unit |
|---|---|---|---|
| 1 | Soil Temperature Sensor | Temperature | °C |
| 2 | Soil Moisture Sensor | Water Content | % VWC |
| 3 | Soil EC / Salinity Sensor | Electrical Conductivity | μS/cm, mS/cm |
| 4 | Soil NPK Sensor | NPK Indicators | Model-dependent |
| 5 | Soil pH Sensor | Acidity / Alkalinity | pH |
| 6 | Soil Heat Flux Sensor | Heat Flux Density | W/m² |
| 7 | Multi-Depth Soil Sensor | Parameters at Multiple Depths | Depends on Parameter |
| 8 | Soil Gas Sensor | Gas Concentration | ppm, % |
| 9 | Soil Water Potential Sensor | Water Potential / Matric Suction | kPa |
| 10 | Portable Soil Tester | One or Multiple Soil Parameters | Depends on Model |
The first six categories and soil water potential or gas instruments represent particular measurement functions. Multi-depth and portable instruments describe how sensors are arranged or used. They can contain one or more of the same sensing technologies.
NiuBoL provides individual and integrated soil sensing equipment for agricultural monitoring. Product selection depends on the actual measurement parameters, operating method and required output interface.
Soil NPK Sensor | Soil Moisture & Temperature | 7-in-1 Soil Sensor |
Soil pH Sensor | Soil EC Sensor | 4-in-1 Soil Sensor |
A soil temperature sensor measures the temperature at a specified depth below the soil surface. Soil temperature influences seed germination, root development, microbial activity, nutrient transformations and the movement of heat through the soil profile.
Common sensing technologies include thermistors and resistance temperature detectors (RTDs). Both use changes in electrical resistance, but they are different types of sensing elements.
An NTC thermistor normally decreases in resistance as temperature rises. A platinum RTD, such as a Pt100 or Pt1000, increases in resistance in a predictable manner over its specified measuring range. The measurement circuit converts resistance into temperature using an appropriate calibration relationship.
Pt1000 is a platinum RTD, not a thermistor. Actual accuracy depends on the sensing element, signal-processing electronics and complete probe design.
Soil temperature sensors are used in agricultural monitoring, greenhouses, forestry, ecological research and soil-profile observation. They are generally installed at a known depth relevant to crop roots or the research objective.
The sensing element should have suitable contact with the surrounding soil. Installation depth, soil disturbance and exposure to direct sunlight near the surface can affect the representativeness of the reading.
A soil moisture sensor estimates the water content of soil around its sensing element. Many agricultural instruments report volumetric water content (VWC), which represents the proportion of a soil volume occupied by water.
Frequency-domain reflectometry (FDR) and time-domain reflectometry (TDR) are commonly used dielectric methods. Water has a much higher relative dielectric permittivity than most dry soil minerals and air, allowing electronic measurements to be related to changes in soil water content.
FDR instruments evaluate the soil's dielectric response using alternating electrical signals or resonant frequency behavior. TDR instruments analyze the propagation of electromagnetic pulses along a measuring structure.
Both techniques require an appropriate relationship between the measured electrical response and volumetric moisture. Their performance depends on sensor design, soil conditions and calibration.
A volumetric water content of 25% means that approximately 25% of the measured soil volume is occupied by water. It does not mean that the air has 25% relative humidity, nor does it mean that 25% of the soil mass consists of water.
Soil texture, bulk density, salinity and temperature may influence dielectric measurements. For some soils, site-specific calibration improves comparability with reference measurements.
Soil moisture sensors are commonly used for irrigation management, greenhouse cultivation, orchards, field crops and soil-water research.
Installation depth should match the crop root zone. Probes should maintain good soil contact without large air gaps or stones around the sensing area. In drip irrigation, the measurement location should represent the intended wetting zone rather than an unusually wet or dry point.
A soil electrical conductivity (EC) sensor measures the ability of the soil environment to conduct electrical current. The result is commonly expressed in microsiemens per centimeter (μS/cm) or millisiemens per centimeter (mS/cm).
Electrode-based soil EC sensors apply a controlled electrical signal and measure the resulting electrical response. Conductivity is influenced by dissolved ions, soil water content, temperature, electrode geometry and other soil properties.
An important distinction exists between bulk soil electrical conductivity and soil solution conductivity. Bulk EC depends on the combined electrical pathways through water, soil particles and interfaces. Soil solution EC refers to the conductivity of the liquid phase.
These measurements are related but are not always directly interchangeable. Soil moisture conditions and the measurement method should be considered when comparing results.
EC can help track salinity-related conditions and changes in ionic concentration, particularly in irrigated agriculture and greenhouse cultivation. It does not identify the specific dissolved ions responsible for conductivity.
Soil EC cannot independently determine nitrogen, phosphorus, potassium or heavy-metal concentrations. Specific nutrient or contaminant analysis requires an appropriate chemical measurement method.
For integrated monitoring, see the Soil EC Sensor product options.
Nitrogen (N), phosphorus (P) and potassium (K) are important plant nutrients. Nitrogen supports vegetative growth, phosphorus contributes to energy-transfer processes and root development, and potassium participates in enzyme activity and plant water regulation.
Soil nutrient measurements may involve laboratory extraction and chemical analysis, specialized ion-selective methods, optical techniques or empirical field indicators. These technologies measure different chemical forms or properties and should not be treated as equivalent.
The NiuBoL Soil NPK Sensor provides displayed nitrogen, phosphorus and potassium indicators derived from conductivity-related electrical measurements and empirical conversion relationships.
This method does not independently isolate and chemically quantify the three nutrients. The displayed NPK numbers are therefore empirical estimates rather than direct laboratory-equivalent concentrations.
Soil moisture, dissolved salts, temperature, soil texture and probe contact can influence electrical measurements. Different soils with similar conductivity may contain very different actual quantities of nitrogen, phosphorus and potassium.
For fertilizer recommendations, quantitative nutrient deficiency assessment and formal soil fertility testing, laboratory analysis and local agronomic guidance remain important.
An empirical field NPK instrument may provide supplementary screening information, but should not be used as the sole basis for determining fertilizer application rates.
A soil pH sensor measures acidity or alkalinity associated with the soil environment. Soil pH influences nutrient availability, microbial activity and chemical reactions relevant to crop growth.
Conventional glass-electrode pH measurement is based on an electrical potential related to hydrogen-ion activity. The measuring electrode and reference system produce a potential difference that the instrument converts into a pH reading using an appropriate calibration relationship.
This is a potentiometric measurement. It should not be described simply as calculating pH from the current generated by a reaction.
Different field pH probes use different electrode structures. Metal-electrode soil probes can provide indicative measurements under suitable conditions, while glass-electrode instruments are commonly used in standardized pH testing procedures.
Measurement repeatability depends on calibration, electrode condition, soil moisture, sample preparation and contact between the electrode and the measured medium.
For applications requiring standardized soil pH results, an appropriate soil-to-solution preparation and laboratory or reference procedure should be used.
A soil heat flux sensor measures the rate at which thermal energy passes through a unit area of soil. Heat flux density is commonly expressed in watts per square meter (W/m²).
A common soil heat flux plate contains a calibrated thermal sensing structure. Heat passing through the plate produces a small temperature difference or thermoelectric signal that is related to heat flux using the plate's calibration coefficient.
Soil heat flux can also be calculated indirectly from a temperature gradient and effective thermal conductivity under appropriate assumptions. However, this is different from directly reading the output of a calibrated heat flux plate.
Heat flux sensors are used in agricultural meteorology, surface energy-balance studies, evapotranspiration research and environmental observation.
The plate should be installed with good thermal contact and minimal disturbance to surrounding soil. Burial depth, differences between plate and soil thermal properties, water movement and installation disturbance can affect the measurement.
For the available instrument, see the Soil Heat Flux Sensor.
A multi-depth soil sensor measures soil parameters at several depths within one soil profile. Unlike a single-depth probe, it can reveal how temperature and moisture conditions differ between shallow and deeper layers.
Water infiltrates from the soil surface and moves through the profile at rates influenced by rainfall, irrigation, soil structure and hydraulic properties. Different depths may therefore respond at different times.
A multi-depth sensor can help identify whether moisture changes occur only near the surface or extend farther into the monitored root zone. This information is useful for evaluating irrigation distribution and observing soil-water changes after rainfall.
Available multi-depth instruments vary in the number of measuring layers, their spacing, sensing principles and supported parameters. Some measure temperature and moisture, while other configurations may add EC or salinity-related outputs.
Installation should provide suitable soil contact at every measuring layer. The surrounding soil should not contain large installation gaps that would create unrepresentative moisture conditions.
For available configurations, see the NBL-S-TM-MD Multi-Depth Soil Sensor.
A soil gas sensor measures the concentration or related properties of gases present within soil pore spaces or collected soil-gas samples. Common target gases include oxygen (O₂), carbon dioxide (CO₂) and gases relevant to specialized ecological or environmental research.
Soil gas measurements may use electrochemical, infrared, optical or other gas-detection methods. The measurement principle depends on the target gas and the instrument design.
For example, certain infrared gas analyzers can measure carbon dioxide concentration, while suitable electrochemical instruments can measure oxygen. Sampling arrangements must be designed for soil-gas conditions rather than assuming an atmospheric gas probe can simply be buried.
Soil gas monitoring is used in soil respiration research, studies of root-zone aeration, ecological monitoring and environmental investigations.
The measured gas concentration can depend on depth, soil moisture, temperature, permeability and sampling method. Gas concentration in a soil pore is also different from the rate of gas exchange between soil and the atmosphere.
A complete gas-flux measurement may require additional chambers, sampling equipment and analytical procedures. A general-purpose soil moisture or temperature sensor does not independently measure soil gas concentration.
A soil water potential sensor measures or estimates the energy state of water in the soil. Soil matric potential describes how strongly water is held by the soil matrix relative to a reference condition.
Water potential is commonly expressed in kilopascals (kPa). For unsaturated soil, matric potential is often negative relative to free water, while some instruments report the corresponding suction magnitude as a positive number.
A conventional tensiometer consists of a water-filled tube, porous ceramic cup and pressure-sensing mechanism. When the ceramic cup is in hydraulic contact with the soil, water exchange creates a negative pressure inside the instrument related to soil matric suction.
As the surrounding soil dries, the suction generally increases within the operating range of the instrument. A conventional water-filled tensiometer cannot measure arbitrarily dry soil because hydraulic continuity can be lost when cavitation occurs.

Soil moisture describes how much water is present. Soil water potential describes the energy state of that water.
The relationship between moisture and potential depends on the soil water-retention characteristics. A sandy soil and a clay soil can contain the same volumetric water content but have very different matric potentials.
For irrigation decisions, water content and water potential can therefore provide complementary information rather than replacing each other.
A portable soil tester is a handheld or transportable device used for field measurements at different sampling locations. The word portable describes its form and operating method, not a separate physical sensing technology.
Depending on the model, a portable instrument may measure soil temperature, moisture, EC, salinity or pH. Some multi-parameter devices also display empirical NPK indicators.
A handheld soil tester typically includes a portable display or data acquisition unit and a sensing probe. Other portable configurations use compatible USB-connected devices and mobile applications.
These designs are useful for spot checks, soil surveys, agricultural inspections and educational applications. They should not be confused with fixed RS485 probes installed continuously in the field.
A portable device may provide convenient readings at several locations, but differences in soil conditions, probe contact and measurement technique can affect comparisons between samples.
For available configurations, see the Portable Soil Testing Device selection page.
Several soil parameters are related, but they do not measure the same physical or chemical quantity. Distinguishing them is important when interpreting monitoring data.
| Comparison | Main Difference |
|---|---|
| Moisture vs Water Potential | Moisture measures water content; potential describes the water energy state. |
| EC vs NPK | EC measures overall conductivity; it does not directly identify individual nutrient concentrations. |
| Soil pH vs Soil EC | pH indicates acidity or alkalinity; EC reflects the ability to conduct electrical current. |
| Soil Temperature vs Heat Flux | Temperature describes thermal state; heat flux describes the rate of heat transfer per unit area. |
| Single-Depth vs Multi-Depth | Multi-depth instruments provide measurements at several soil layers instead of one location. |
| Fixed vs Portable | Fixed sensors support repeated or continuous monitoring; portable instruments support measurements at selected locations. |
Sensor selection should start with the measurement objective and the decisions that will be based on the data. A soil moisture sensor may be sufficient for a basic irrigation project, while research and multi-zone agricultural systems may require several complementary measurements.
| Monitoring Objective | Sensors to Consider |
|---|---|
| Irrigation Scheduling | Soil Moisture and/or Water Potential |
| Root-Zone Monitoring | Soil Moisture, Temperature and Multi-Depth Measurements |
| Soil Salinity Monitoring | Soil EC, Moisture and Temperature |
| Soil Acidity Monitoring | Soil pH Measurement |
| Quantitative Nutrient Analysis | Appropriate Laboratory Soil Testing |
| Surface Energy Balance | Soil Heat Flux and Temperature Sensors |
| Soil Respiration Research | Suitable Soil Gas Sampling and Measurement Equipment |
| Rapid Field Inspection | Portable Soil Testing Instruments |
For a practical product comparison, see the Soil Sensor Selection Guide.
Many agricultural soil sensors provide electrical outputs compatible with PLCs, RTUs or environmental data loggers. Available output interfaces depend on the selected instrument and configuration.
RS485 Modbus RTU is commonly used for digital soil monitoring. Analog outputs such as 4–20mA or voltage signals are also available on selected models.
Soil Sensor → RS485 / Analog Output → Data Logger or PLC → Communication Gateway → Monitoring Platform
4G, Ethernet, Wi-Fi and LoRaWAN communication require compatible gateways or wireless nodes. A standard wired soil sensor should not be assumed to include remote network transmission.
When several RS485 sensors share a bus, device addresses, communication parameters, wiring, power supply and input capacity must be configured correctly.

Common types include soil temperature, moisture, EC, pH, nutrient-indicator, heat flux, gas and water potential sensors. Multi-depth and portable soil instruments are also commonly used configurations.
Soil moisture and water potential sensors are commonly considered for irrigation monitoring. Additional soil temperature, EC or multi-depth measurements may be useful depending on the crop and soil conditions.
No. Soil EC measures overall electrical conductivity and does not independently determine individual nutrient concentrations. EC-based NPK indicators are empirical estimates rather than direct chemical measurements.
Soil moisture describes the amount of water present, while soil water potential describes its energy state. Their relationship depends on soil water-retention properties.
Yes. Integrated soil probes can combine temperature, moisture, EC, salinity, pH and other supported measurements. The actual sensing methods and limitations of each parameter should be checked for the selected product.
The number depends on field size, soil variability, crop rooting depth, irrigation zones and the monitoring objective. Several sensors or measurement depths may be required to represent different soil conditions.
NiuBoL provides soil monitoring instruments for moisture, temperature, electrical conductivity, pH, empirical NPK indicators and multi-depth measurements, together with compatible data acquisition equipment.
For available products and specifications, explore the NiuBoL Agricultural Sensors category.
For model selection, specify the required measurement parameters, soil type, sensing depth, output interface, power supply, cable length, number of monitoring points, data logger or PLC compatibility and project quantity.
